5601-W - Genuine OEM Leviton Decora Wall Light Switch, 15A, 120/277V, White

5601-W - Genuine OEM Leviton Decora Wall Light Switch, 15A, 120/277V, White

The 5601W Genuine OEM Leviton Decora Wall Light Switch is a single-pole, 15-amp electrical wall switch designed for AC applications rated at 120/277 volts. This white Decora rocker switch provides reliable on/off control for compatible lighting and electrical loads in residential and other suitable installations.

The Leviton 5601W features a quiet rocker design, self-grounding construction, thermoplastic actuator and body, and both side-wire and Quickwire push-in termination options. Product specifications identify it as a 15A, 120/277V single-pole Decora switch.

Appliance Kingdom is a Canadian supplier serving homeowners, landlords, property managers and professional technicians across Canada. The 5601W is available for Canadian customers with Canada-wide shipping and support to help confirm that the electrical specification is appropriate before purchase.

What Does the Leviton 5601W Wall Switch Do?

The Leviton 5601W is a single-pole wall switch used to control an electrical load from one switch location. Its rocker actuator provides straightforward on/off operation while its 15A, 120/277V rating is intended for compatible AC electrical applications.

The switch uses a thermoplastic actuator and body with a steel mounting strap. Its self-grounding design and available side-wire and Quickwire termination methods provide installation flexibility when used in an appropriate electrical box and wiring configuration.

Using a switch with the correct amperage, voltage, pole configuration and wiring method is important for safe and reliable electrical operation. Always confirm that the switch specification matches the intended circuit and installation requirements.

Common Symptoms Indicating a Wall Switch May Need Replacement

A wall switch may require replacement when you experience symptoms such as:

• The connected light or load does not turn on or off reliably

• The rocker feels loose, damaged or unusually difficult to operate

• The switch intermittently loses electrical continuity

• The connected light or load remains on when the switch is operated

• The switch shows visible physical damage or excessive wear

• The switch no longer provides consistent on/off control

A failed wall switch is not the only possible cause of these symptoms. Wiring, the connected load, circuit protection and other electrical components can also be responsible.

Will Replacing the 5601W Fix My Electrical Problem?

Replacing the switch can resolve the problem when the 5601W is being used in a compatible installation and the existing wall switch itself has failed.

However, symptoms such as a light not operating can have several electrical causes. Before replacing the switch, the circuit should be properly diagnosed. If you are unsure whether the switch or another component is responsible, consult a qualified electrician.

Compatibility & Ordering Guidance

The 5601W is a single-pole Decora wall switch rated for 15A and 120/277V AC applications.

Before ordering, verify:

• The required switch type is single-pole

• The circuit voltage is appropriate for the switch

• The circuit's required amperage is compatible with the switch rating

• The existing wiring configuration is suitable for the switch

• The physical wall-box and Decora installation requirements are appropriate

If you are replacing an existing switch, compare its electrical specifications and wiring configuration with the 5601W before ordering.

Key Features & Benefits

• Genuine OEM Leviton wall switch

• Part number: 5601W

• Decora rocker-style design

• Single-pole operation

• 15A rating

• 120/277V AC rating

• Self-grounding construction

• White finish

• Thermoplastic actuator and body

• Steel mounting strap

• Side-wire terminals accommodate #10, #12 and #14 AWG copper conductors and #10 and #12 copper-clad conductors

• Quickwire push-in terminals accept #14 AWG solid copper conductors

• Suitable for compatible residential electrical installations

Installation Overview

Installation of a wall switch involves working directly with electrical wiring and should be treated as an electrical repair rather than a simple appliance-parts replacement.

An experienced and appropriately qualified DIYer may be able to install the switch where permitted by local electrical requirements. Power must be disconnected before working on the circuit, and the wiring configuration should be verified before installation.

If you are not qualified or comfortable working with live electrical systems, professional installation by a licensed electrician is recommended.

Canada-Wide Availability & Appliance Kingdom Support

Appliance Kingdom is a Canadian appliance and replacement-parts supplier based in Edmonton, Alberta, serving customers across Canada.

The 5601W is available for Canadian customers looking for a genuine OEM Leviton Decora wall switch. We support homeowners, landlords, property managers and professional technicians nationwide.

Before purchasing, customers can contact Appliance Kingdom for assistance confirming the product specifications against their existing component or installation requirements.

Buyer Confidence

The Leviton 5601W is identified as a Leviton-manufactured 15A, 120/277V single-pole Decora switch. Its published specifications include self-grounding construction, a thermoplastic body and actuator, and multiple wiring termination options.

For the best installation confidence, verify the electrical requirements of your existing circuit before ordering. If you are uncertain about the correct switch specification, professional electrical advice is recommended.
